55” UHD DLED TV
Model：LE-24Z1-530
Solution：Hi3751
Market：Asia Pacific
Resolution：3840*2160
Screen Size：55 Inches
Aspect Ratio：16:9
Model：LE-24Z1-530
Solution：Hi3751
Market：Asia Pacific
Resolution：3840*2160
Screen Size：55 Inches
Aspect Ratio：16:9
Panel Maker
INNOLUX
Display type
DLED
Aspect ratio
16:9
Resolution
3840*2160
Brightness
180cd/㎡
Contrast
3000:1
Viewing Angle
178°* 178°
Maximum Colors
16.7M
Response Time
8.5ms
Solution
Hi3751 With AC-3
OS
Android 5.1
Memory
4GB/8GB Flash
768MB RAM Inside
CPU/GPU
A53*2, Mali450*4
Comb Filter
3D
Video System
PAL SECAM
Progressive Scan
YES
HD Ready
YES
YPbPr Resolution
480i/p,576i/p,720i/p,1080i/p
PC Resolution
UP to 1920×1080 @60Hz
Color Temperature Adjustment
YES
Audio System
B/G,D/K,I
Stereo Sound
NICAM
Maximum Audio Output
2×8W
Equalizers
YES(4 Modes)
Effects
YES
PC Audio In
1
TV
1
COAX
1
HDMI
2
USB（3.0）
1
USB(2.0)
1
RJ45
1
AV IN
1
VGA(D-Sub 15pin)
1
YUV
1
(Mini)Line out
1
TF Card
1
Power Requirement
100-240 @50/60Hz
Power consumption(Operation)
≦135W
Power consumption(Standby)
≦0.5W
ETL
/
FCC
/
UL
/
Remote controller(English)
YES
Wall-mount Bracket
OPTIONAL
Remote Batteries
YES
User Manual
YES
