GPU: Intel® ARC TM Graphics 5
LCD: 14″ 16:10,1920*1200 FHD IPS
Capacity: 50Wh/11.55V or 65Wh/11.55V (Optionalal)
Endurance time: >8 Hours
Camera: 720P(standard),1080P(PCBA Optionalal),IR Camera(PCBA Optionalal)
Dimension: 313*224*16.6mm
Structure
Form
Dimension
Material
Hinge
Weight
Notebook
313*224*16.6mm
Full Metal
180 degree hinge
1500g
LCD
Dimension
Resolution
14″ 16:10
1920*1200 FHD IPS
CPU
Module
Intel MTL(U/H)
Intel® Core™ Ultra 7 165H 28W
Intel® Core™ Ultra 7 155H 28W
Intel® Core™ Ultra 5 135H 28W
Intel® Core™ Ultra 5 125H 28W
GPU
Model
Intel® ARC TM Graphics 5
Memory
RAM
LPDDR5x*4，Up to 32GB (onboard)
Storage
SSD
1*PCIE GEN4 x4 or SATA3.0 (M.2 2280), up to 1TB
Touch panel
Form
N/A
IO Interface
MB IO(Left)
MB IO(Left)
MB IO(Left)
MB IO(Left)
MB IO(Left)
DB IO(Right)
DB IO(Right)
DB IO(Right)
DB IO(Right)
DB IO(Right)
DB IO(Right)
MB IO(Rear)
φ3.5 Standard DC Port (MB) (Optional)
HDMI Type A 2.0(MB)
USB3.2 Gen1 Type-A(MB)
USB 3.2 Gen1 Full function Type C (MB)
USB 3.2 Gen1 Full function Type C (MB) or USB2.0 date Type C (MB)
Security lock slot(Mini Saver)(DB)
USB 3.2 Gen1 Type-A(DB)
USB 2.0 Type-A(DB)
Φ3.5mm standard headphone jack(DB)
USB 2.0 date Type C (DB)
Camera+Mic physical power on/off switch
N/A
LED indicator
1x Power On/Off/Sleep
1xBattery/Charge
1xWebcam
1xCaps Lock
On with White light
Off with no light
Sleep with breathing light
On with Red light
Off with no light
On with Green light
Off with no light
On with White light
Off with no light
Power Key
Button
Seperated Power button key(On DB)
Keyboard
Back light
Matrix
Optionalal
US
Web camera
Front
Rear
Windows Hello
720P(standard)
1080P(PCBA Optionalal)
IR Camera(PCBA Optionalal)
N/A
Optionalal
Touchpad
Interface type
Feature
SPI
multi-touch support, gestures and scroll function
Fingerprint
Location
Windows Hello
On the Touchpad
Fingerprint (Optionalal) Windows Hello compatible(Optionalal)
N/A
Audio
Speaker
Mic
Others
Built-in 4Ω/1W speaker *2+8Ω/0.8W speaker*1
Built-in (dual) digital microphones
N/A
Battery
Type
Capacity
Certification
Battery life
Lithium-ion polymer battery, fast charging Optionalal.
50Wh/11.55V or 65Wh/11.55V (Optionalal)
CB，MSDS，UN38.3，空运鉴定报告
>8 Hours
Sensor
G sensor
Hall sensor
N/A
Support
TPM
interface Type
fTPM2.0, dTPM Optionalal(SPI)
RTC
RTC Connector
YES
Others
N/A
WIFI
Wifi Chip Model
Others
WiFi5 802.11 ac with BT 5.0, MIMO 2*2
Wifi 6 802.11 ax with BT 5.2 dual band 2*2
N/A
LTE
M.2 slot
N/A
Bluetooth
Bluetooth
Version
Support
BT 5.0/ 5.2
Operating System
System
Language Support
Windows11
Support multi Language
AI in Windows
AI in Windows
AI in Windows
AI in Windows
AI Software
AI Software
AI Software
MEP
（need OEM get approval from Microsoft）
MEP
（need OEM get approval from Microsoft）
MEP
（need OEM get approval from Microsoft）
Copilot
(Support Region depends on Microsoft)
Large language model (License requirement)
Text to Image model (License requirement)
Image to Image model (License requirement)
Automatic framing
Eye contact
Background effect
Support
Support
Support
Support
BIOS/EC
UI spec
Standard spec
Power adapter
Standard Configuration
65W/20V DC/Type-C charger
