42″ HD DLED TV (LE-42Z1-3663)

42″ HD DLED TV

Model:LE-42Z1-3663
Solution:MSD3663S/MSD3663
Market:Asia Pacific/Europe/South America
Resolution:1920*1080
Screen Size:42 Inches
Aspect Ratio:16:9

Categories: ,

Description

Specifications

Panel Maker

INNOLUX

Display type

DLED

Resolution

1920*1080

Brightness

250cd/㎡

Contrast

4000:1

Viewing Angle

178°* 178°

Maximum Colors

16.7M

Response Time

9.5ms

Solution(AP+LA)

MSD3663

Solution(EU)

MSD3663S

OS

NO

Memory

128B RAM Inside

Comb Filter

3D

Video System(AP+EU)

PAL SECAM

Video System(LA)

ATV:PAL,NTSC/DTV:ISDB

Progressive Scan

YES

HD Ready

YES

YPbPr Resolution

480i/p,576i/p, 720i/p,1080i/p

PC Resolution

UP to 1920×1080 @60Hz

Color Temperature Adjustment

YES

Audio System(AP+EU)

B/G,D/K,I

Audio System(LA)

M/N

Stereo Sound(AP+EU)

NICAM

Stereo Sound(LA)

YES

Maximum Audio Output

2×8W

Equalizers

YES(4 Modes)

Effects

YES

AV IN(LA)

1

CI(EU)

1

COAXIAL

1

CVB&YPBPR(AP)

1

EARPHONE(LA)

1

EARPHONE OUT(EU+AP)

1

HDMI

3

L/R AUDIO IN(AP)

1

MINI AV(EU)

1

MINI YPBPR(EU)

1

PC AUDIO IN

1

S2(EU)

1

SCART(EU)

1

TV(EU+AP)

1

USB

1

VGA(EU+AP)

1

VGA(D-Sub 15pin) (LA)

1

YPBPR (LA)

1

Power Requirement

100-240 @50/60Hz

Power consumption(Operation)

≦70W

Power consumption(Standby)

≦0.5W

ETL

NO

FCC

NO

UL

NO

Remote controller(English)

YES

Wall-mount Bracket

OPTIONAL

Remote Batteries

YES

User Manual

YES

Stand

YES

Packing

Unit(mm)

944.3*548.5*79

1Pc/1Carton

(mm)

1024*146*640

Net(Kg)

6.5

1Carton(Kg)

8.5

40HQ

690PCS
