27″ F Series Monitor (LM-27F1)

27″ F Series Monitor – LM-27F1

Model:LM-27F1
Resolution:1920*1080
Contrast: 3000 : 1
Response Time:12ms Typ
Max. display frequency:1920*1080 75Hz for VGA 、HDMI
Screen Size:
27 Inches
Aspect Ratio:16:9

Categories: ,

Description







F Series Business Monitors

The new Express LUCK F Series business monitors are designed for work and entertainment at your office or at home. Available from 22” to 27” with two colors that can match your professional workplace.







True Color in FHD

Presenting clear, true color images by FHD, which displays colors richly and accurately. FHD display makes your beautiful photos and graphics come alive.









Flexibility and Style

With our incredibly slim design monitor and three types of stands, you can choose a suitable stand according to your style and the one best fit in your desk.







USB Type-C™ High-Performance Connection

The monitor has the latest USB Type-C connection that supports 15W charging. You can enjoy the convenience of image and data transfer by charging by one cable and synchronizing the monitor with devices like laptops and smartphones.

Specifications

Curved / flat

Flat

OC

AUO M270HVN02.0

Surface Treatment

Anti-Glare,Haze 25%, Hard Coating (3H)

Panel type (Display Mode)

VA panel

Brightness(Typical)

250 cd/m2 (Typ.)

Contrast(Typical)

3000 : 1

Pixel Pitch(mm)

0.31125(H) *0.31125(V)

Resolution (H x V)

1920*1080

Aspect Ratio

16:9

Response Time(Typical)

12ms Typ

View Angles LR,UD(CR=10)

178°(H) /178°(V)

Display Colors

16.7M

NTSC(Area)

72%

Anti-flicker

Yes

G-Sync

NA

Free Sync

Ready

Anti-Bluelight

Yes

HDR/DCR

HDR 10

Over Drive

NA

Anti-glare

Yes

Daisy Chain

NA

Horizontal Freq.

55k~90KHz

Vertical Freq.

50 to 76HZ

Max. display frequency
(Resolution H*V/Fv)

1920*1080 75Hz for VGA 、HDMI

VGA

x1

HDMI1.4

x1

Type-C

Yes

Output Type-C

Output 18W MAX

Earphone

x1

Speaker(Typical, Amplifier output)

optional 4Ω 2W*2 (mainboard support 2W*2)

Back Control

Yes

On Screen Display

12 Language: English, French, German, Chinese, Italian, Spanish, Portuguese, Turkish, Polish, Dutch, Korean, Japanese

Color

6500、7500、9300、User

Preset Mode

GAME、MOVIE、PHOTO、STADNARD

Consumption(Typical)

On: <48 W
Standby<=0.5W, Off<=0.5W

AC Power Range

100-240V~, 50/60Hz

Power Mode

Adaptor 12V4A

Tilt

-5°~15°(+/-2°)

High Adjustable Arm

optional

Swivel

optional

Kensington Lock

Yes

VESA Mounting

100×100 (screw hole: 4 holes with M4 x 8 mm)

Power Adaptor

Plug-in adaptorx1

HDMI Cable(1.5m)

x1

Stands

Assembling stand and base with one M5*10mm screw, the stand and monitor should be easy install , no need screw

User Manual

x1

Packing

With Stand(W*D*H)

613.0*443.77*170.1mm (metal stand /base)
613.0*460.54*188.03mm (VESA stand /base)

Without Stand(W*D*H)

613.0*361.45*56.1mm

With Package(W*D*H)

673*114*421mm

Net Weight

Gross Weight

Loading alibilty
W/O Pallet

20′ GP/40GP/ 40′ HQ
938/1928/2196

Loading alibilty

20′ GP/40GP/ 40′ HQ
700/1470/1596

Pallet

20′ GP/40GP/ 40′ HQ
10/21/21
